型 号
Model
技术参数
Specifications |
BX216 |
BX218 |
BX218D |
BX2110 |
BX2113A |
BX2113B |
BX2113C |
BX2116 |
刀辊直径 (mm)
Rotor diameter |
650 |
800 |
800 |
1000 |
1300 |
1300 |
1300 |
1600 |
飞刀数 (把)
Number of flying knives (pc) |
2 |
2 |
2 |
2×2 |
3 |
3×2 |
4×2 |
4×2 |
进料口尺寸 (mm)
Feed opening |
180×500 |
225×680 |
240×780 |
330×1050 |
400×700 |
400×1050 |
400×1250 |
600×1250 |
刀辊转速 (rpm)
Knife rotor speed |
590 |
650 |
650 |
550 |
420 |
442 |
378/340 |
350 |
进料速度 (m/min)
Feed speed |
37.2 |
37 |
38 |
33 |
38 |
43 |
36/42 |
42 |
加工原料最大直径
Processing raw material max diameter (mm) |
120 |
160 |
160 |
190 |
230 |
240 |
250 |
310 |
木片长度 (mm)
Wood Chips length |
30 |
30 |
30 |
30 |
30 |
32 |
24/32 |
30 |
生产能力(实积)(m3/h)
Capacity |
10 |
15-20 |
38 |
75 |
60-70 |
100 |
130 |
180 |
主电机功率(KW)
Main motor power |
55 |
110 |
132 |
220 |
250 |
315 |
450 |
710 (10kV) |
喂料辊电机功率(KW)
Feed roller motor power |
2×3 |
2×4 |
2×5.5 |
2×7.5 |
2×7.5 |
2×11 |
2×15 |
2×18.5 |
油泵电机功率(KW)
Oil pump motor power |
|
|
0.37 |
3 |
3 |
3 |
3 |
4 |
重 量(kg)
Weight |
4070 |
7000 |
8000 |
12500 |
13840 |
16700 |
18000 |
32000 |
外型尺寸mm(长×宽×高)Overall dimensions
(L×W×H) |
4348×2056
×1258 |
4670×2150
×1500 |
4670×2250
×1515 |
2850×2799
×1497 |
3670×2517
×2050 |
3485×2350×
1828 |
5484×5400
×1862 |
4360×3150×
2200 |
